4 Slot Linear Diffuser
METALAIRE is the flagship brand of Metal Industries Inc., offering a complete line of air distribution and air terminal products. From standard grilles and registers, to its architectural line of Formations® linear slot diffusers, along with a newly released series of displacement diffusers, METALAIRE has the air devices to meet every need. Slot diffusers can be installed individually in set lengths or in a continuous line. They can also be installed in any type of ceiling application. The modules are available with a 20mm or 25mm Slot with the number of slots ranging from 1 to 8 slots.
4 Slot Linear Diffuser
Sleek and unobtrusive, TRUaire LD linear slot diffusers are the architects dream come true. Long narrow slots take the place of traditional 'fins'. The installation is flush with the wall or ceiling, and the diffuser all but disappears within the natural lines of the structure.
- Capped on both ends
- 1/2', 3/4', or 1' wide 4 row/slot models
- Durable white powder coat finish
- Installation brackets with screws
- Available in 2', 3', 4' & 6' stock lengths
- Overall size is LISTED SIZE + 2-1/2'
| Do you have questions about the products on this page? Click on the ? image on the left or this link to ask us your questions! |
No questions yet. Be the first and send us your question! |
Related Products
TRUaire LD Linear Slot Diffusers - 1 Slot
Sleek and unobtrusive linear diffusers. Available in 2', 3', 4' & 6' stock lengths. 1 slot.
TRUaire LD Linear Slot Diffusers - 2 Slots
Sleek and unobtrusive linear diffusers. Available in 2', 3', 4' & 6' stock lengths. 2 slots.
TRUaire LD Linear Slot Diffusers - 3 Slots
Sleek and unobtrusive linear diffusers. Available in 2', 3', 4' & 6' stock lengths. 3 slots.
- residential
- AirFlow Boosting
- Grilles & Registers
- Air Handlers
- Attic Fans & Vents
- Bathroom Ventilation
- Boosters & Exp Tanks
- Crawlspace-Radon Ventilation
- COVID-19 Mitigation
- Condensate Pumps
- Dryer-boosting
- Fans
- Filters, HEPA & Filter Boxes
- HRVs and ERVs
- Floor Heating
- Indoor Air Quality - IAQ
- Kitchen Exhaust
- Makeup Air
- Pumps & Instant Hot Water
- Tankless & Flue Venting
- Thermostats and Fan Controls
- Title 24 Products
- Whole House Fans
- Wine Cellar Coolers
- Ventilation Accessories
why buy from us?
We're engineers passionate about home ventilation and serious about customer service – so you can count on us for carefully-selected equipment and expert advice to ensure your project is a success from specification to installation.
Your call is answered by qualified people who will gladly discuss your project in detail, advise you professionally and never sell you inappropriate products.
Sleek and unobtrusive, TRUaire LD linear slot diffusers are the architects dream come true. Long narrow slots take the place of traditional 'fins'. The installation is flush with the wall or ceiling, and the diffuser all but disappears within the natural lines of the structure.
- Capped on both ends
- 1/2', 3/4', or 1' wide 2 row/slot models
- Durable white powder coat finish
- Installation brackets with screws
- Available in 2', 3', 4' & 6' stock lengths
- Overall size is LISTED SIZE + 2-1/2'
| Do you have questions about the products on this page? Click on the ? image on the left or this link to ask us your questions! |
| #1 | Q: What is the CFMs I can get from this unit? Thank you A: Depends on the size you are looking at and the fan pushing the air. Here is the performance sheet for these (CFM vs pressure drop): https://www.hvacquick.com/catalog_files/TRUaire_LD_Performance.pdf Asked on 2019-05-19 by Joseph |
|---|---|
| #2 | Q: I am making the boxes the slot diffuser will slip into, how will the diffusers be secured in place? Should we put a flange on the box? A: Slot diffusers boxes have a flange (bent upwards, almost hemmed) on the long sides. The Truaire slots come with the C brackets that slip into the bent flages and lock in. The diffusers are secured by screwing through the slots into the C bracket. The holes are pre-drilled in the diffusers. Asked on 2019-01-17 by Chris |
| #3 | Q: Dear Sales@ HVACIm interested in the TRUaire LD Linear Slot Dff., however even though my choice length is 24, i cannot figure out how to select the width of 6. A: What you see on the page are the only sizes available. Truaire does not offer other width sizes. Asked on 2018-11-05 by FG |
| #4 | Q: is there a way to connect this to a 4 opening ceiling fan duct? A: You would need a metal plenum that converts the rectangular shape to round. The round outlet is typically on the side of the plenum (box) since the top is narrow. We do not sell them, but you can buy plenums for linear diffuses from local sheet metal shops. Asked on 2016-12-08 by Andrea |
| #5 | Q: Is there an adjustable damper inside diffuser? A: Yes, each slot has 2 movable parts that are used to adjust the airflow. Asked on 2016-05-12 by Tony |
